Dimensioning with snap function or automatically from
dimensioned DXF target contour with »lasso«
Detailed inspection with zoom and colored display of
exceeded limits with »lasso«
close [x]
close [x]
Author: Robert Auer
Further information:
Contour profile measurement for
tools and tool geometries: »lasso«
ƒ ƒ Fast scanning, measuring and analysis
ƒ ƒ Fully automated contour measurement
with target-actual comparison
ƒ ƒ Clearly arranged user interface, including
integrated help function
ƒ ƒ Easy definition of the contour range by
entering the start and end points
You prefer TV to reading?
No problem!
On our YouTube station
»zollertv« you can find
an abundance of videos,
which will bring you the
world of ZOLLER even
closer:
Process monitoring, quality control and documenta-
tion – every grinding and sharpening business is aware
of the subject. Especially when it comes to complaints!
In-process monitoring and quality control are becoming more and
more important due to the increasing complexity of the tools, but also
due to customer demands for inspected, documented quality pro-
ducts.
No reworking, no complaints any more!
So it was hardly surprising that the topic of inspecting tools, mea-
suring and QA documentation was a central theme of discussion at
the annual meeting of the FÖPW. Several solutions on the topic „In-
spection & QA“ were presented to interested members of the FÖPW
in a relaxed atmosphere at the ZOLLER presentation center in Ried im
Innkreis.
Quality to convince customers and users
One highlight was the contour profile measurement with »lasso«.
This allows scanning, measuring and automatic analysis of a target-
actual comparison for any tool or workpiece geometry. Fully automated
dimensioning according to target specifications then prepares the
documentation – the tool has been inspected completely and the
results are documented. This precludes tedious reworking and
complaints and ensures quality which will convince you and your
customers.
The ensuing discussions showed that the topics inspection, docu-
mentation and traceability in particular, were increasing in importan-
ce – above all, to enable high quality and cost-efficient manufactu-
ring. To be on the safe side, always swing your »lasso«. Yee-haw!!!
